产品介绍
接口的分类一般有：DB9\DB25\BNC\HDMI\USB\RJ45\VGA\TNC；
产品型号定义
接口滤波器选型表
| 型号 | 信号类型 | 额定电流（A） | 额定电压（V） | 工作频率（Hz） | 接口数量 | 气候类别 | 屏蔽效能 | 屏蔽效能 |
| 频率 | ||||||||
| FS-DB9-JK | 串口 | 2 | 50VDC | / | 1 | 25/70/21 | 0.45-10GHz | 70dB |
| FS-DB9-JK2 | 串口 | 2 | 50VDC | / | 2 | 25/70/21 | 0.45-10GHz | 70dB |
| FS-V8-JK | 百兆网络 | 2 | 50VDC | / | 1 | 25/70/21 | 0.45-10GHz | 70dB |
| FS-V8-JK2 | 百兆网络 | 2 | 50VDC | / | 2 | 25/70/21 | 0.45-10GHz | 70dB |
| FS-KWY-JK | 千兆网络 | 2 | 50VDC | / | 1 | 25/70/21 | 0.45-10GHz | 70dB |
| FS-KWY-JK2 | 千兆网络 | 2 | 50VDC | / | 2 | 25/70/21 | 0.45-10GHz | 70dB |
| FS-USB2.0-JK | USB2.0 | 2 | 50VDC | / | 1 | 25/70/21 | 0.45-10GHz | 70dB |
| FS-USB2.0-JK2 | USB2.0 | 2 | 50VDC | / | 2 | 25/70/21 | 0.45-10GHz | 70dB |
| FS-USB3.0-JK | USB3.0 | 2 | 50VDC | / | 1 | 25/70/21 | 0.45-10GHz | 70dB |
| FS-HDMI-JK | 视频信号 | 2 | 50VDC | / | 1 | 25/70/21 | 0.45-10GHz | 70dB |
| FS-VGA-JK | 视频信号 | 2 | 50VDC | / | 1 | 25/70/21 | 0.45-10GHz | 70dB |
| FS-DB25-JK | 串口 | 2 | 50VDC | / | 1 | 25/70/25 | 0.45-10GHz | 70dB |
| FS-FT1B-JK | 电源 | 10 | 110/250VAC | 50/60Hz | 1 | 25/70/21 | 0.45-10GHz | 70dB |
| FS-BNC5-JK2 | BNC50Ω | 5 | 50VDC | / | 2 | 25/70/21 | 0.45-10GHz | 70dB |
| FS-BNC7-JK2 | BNC75Ω | 5 | 50VDC | / | 2 | 25/70/21 | 0.45-10GHz | 70dB |
接口滤波器尺寸表
| 产品型号 | 图号 | 产品尺寸 | ||||||||||
| A | B | C | D | E | F | H | Q | K | L | J | ||
| FS-DB9-JK |  | 152 | 110 | 60 | 84 | 75 | 48 | 36 | / | 100 | 50 | 4.2 |
| FS-DB9-JK2 |  | 152 | 110 | 82 | 84 | 75 | 70 | 58 | 22 | 100 | 50 | 4.2 |
| FS-V8-JK |  | 132 | 110 | 60 | 84 | 65 | 48 | 36 | / | 100 | 50 | 4.2 |
| FS-V8-JK2 |  | 152 | 110 | 82 | 84 | 75 | 70 | 58 | 22 | 100 | 50 | 4.2 |
| FS-KWY-JK |  | 132 | 110 | 60 | 84 | 65 | 48 | 36 | / | 100 | 50 | 4.2 |
| FS-KWY-JK2 |  | 152 | 110 | 82 | 84 | 75 | 70 | 58 | 22 | 100 | 50 | 4.2 |
| FS-USB2.0-JK |  | 132 | 110 | 60 | 84 | 65 | 48 | 36 | / | 100 | 50 | 4.2 |
| FS-USB2.0-JK2 |  | 132 | 110 | 60 | 84 | 65 | 48 | 36 | / | 100 | 50 | 4.2 |
| FS-USB3.0-JK |  | 132 | 110 | 60 | 84 | 65 | 48 | 36 | / | 100 | 50 | 4.2 |
| FS-HDMI-JK |  | 162 | 110 | 82 | 84 | 80 | 70 | 58 | / | 100 | 50 | 4.2 |
| FS-VGA-JK |  | 162 | 110 | 82 | 84 | 80 | 70 | 58 | / | 100 | 50 | 4.2 |
| FS-DB25-JK |  | 152 | 125 | 60 | 95 | 75 | 50 | 30 | / | 115 | 65 | 3.5 |
| FS-FT1B-JK |  | 130 | 102 | 66 | 75 | 64 | 55 | 43 | / | 90 | 50 | 3.5 |
| FS-BNC5-JK2 |  | 112 | 85 | 60 | 55 | 55 | 45 | 30 | / | 70 | 35 | 4.2 |
| FS-BNC7-JK2 |  | 112 | 85 | 60 | 55 | 55 | 45 | 30 | / | 70 | 35 | 4.2 |
